Compuprint MDP40B Uživatelský manuál stáhnout pdf (Strana 58)

54

P

P

a

a

s

s

s

s

b

b

o

o

o

o

k

k

s

s

w

w

i

i

t

t

h

h

H

H

o

o

r

r

i

i

z

z

o

o

n

n

t

t

a

a

l

l

F

F

o

o

l

l

d

d

Dimension

Maximum

Minimum

A Passbook width 213 mm 102 mm

B Passbook length 210 mm 127 mm

C Distance between print

character position and

left or right edge

- 3.0 mm

D Distance between top

edge of the document

and top edge of first

printed line

- 6.6 mm

E Distance between

bottom of last printed

line and bottom edge of

the document

- 6.6 mm

F Outer corner radius 9.35 mm -

G Distance from fold to

bottom of the first

printed line above the

fold.

- 5.1 mm

J Distance from fold to

top of the first printed

line below the fold.

- 5.1 mm

Insertion direction

B

Print Area

Print Area

C

C

D

F

G

H

ABCD

ABCD
